TRANSPORTATION

 The Transportation Department provides its services in the areas of roads, airports, rails, traffic, road asset management systems, intelligent transport systems, and areas related to technological development. Our transportation division provides services, such as survey works,  visual inspection, topographic mapping, engineering design, construction of transportation facilities, supervision of construction, quality control, road management systems preparations, maintenance, and supervision of maintenance operations.

We can fairly assist on production of drawings for owners, contractors, suppliers, manufacturers, subcontractors, or fabricators. Also, we provide smart solution for Problems with design coordination, such as time consumption and ineffectiveness related to the current 2D paper-based process. we can provide an early conflict solving to increases correction the potential for errors in the field decrease. We use specific professional methods for easy review and distribution of comments. We believe that facilitating quick review is an essential part of the approval process and mutually provide ample opportunity for comments. We provide shop drawings in various forms, depending upon the needed practice of the project.

We divide any transportation project into clear phases. with clear duties and deliverables to insure professionalism and project success as follow:

Phase

Deliverable

1- Data Collection Phase

  • Collect Client requirements
  • Detailed Corridor Survey
  • Soil Investigation
  • Hydrological Data
  • Traffic Data
  • Utilities Crossing and connection
  • Future Utility requirements
  1. Survey drawings
  2. Soil Investigation report
  3. Hydrology study
  4. Traffic study
  5. Utility Agencies requirements for current and future stages

2- Preliminary Design

  • Set Design Standards (AASHTO, Egyptian Code, BS, Municipality standard, etc.)
  • Set Design Criteria
  • Project Preliminary Design
  1. Concept Design Report
  2. Utilities NOC design
  3. Road Structure design
  4. Slope stability Report
  5. Preliminary design

3- Utility Coordination

  • Coordination with all concerned utility agencies
  1. NOC design from Utility agencies

4- Detailed Design

  • Detailed design and tender documents preparation
  1. Detailed Design Drawings
  2. Project specification
  3. Project BOQ
  4. Project Tender document
5- Construction Supervision
  • Appoint supervision staff
  • Quality Control to all site work
  • Coordinate constructions schedule with the contractor
  • Coordinate traffic detour with police department (if needed)
  • Develop project specific construction standards, forms, communication protocol, change management, cost management and contract management)
  • Develop As-Built drawings after finishing the project
  • Develop project closure documents
  1. Project staff
  2. Project Schedule
  3. Traffic detour plans (if needed)
  4. Project Specific Construction Manual
  5. Quality control requests submissions
  6. Monthly Reports to the client
  7. Bi Weekly Dash Board to follow up all the project activities with High level project progress summery
  8. Revise and submit all implemented quantities
  9. Revise and submit all invoices
  10. Revise and submit As-Built drawings
  11. Revise and submit all project closure documents
